Elitech PG-30Pro Digital Manifold Gauge, Digital Pressure Gauge -14.5~500 psi

Elitech PG-30Pro Digital Manifold Gauge, Digital Pressure Gauge -14.5~500 psi

Category： Digital vacuum gauge ,pressure gauge
INQUIRY EMAIL

Elitech PG-30Pro is a digital pressure gauge that measures system pressure in real-time. It features a big artistic screen and batteries with 1-year service life. The gauge has a backlight, auto-off, low battery indication, overload alarm, and other functions. It is designed for use in the piping system, refrigerated systems, and other applications.

Product Features

Stable and reliable* temperature-compensated pressure sensor with temperature drift not exceeding 0.05%FS.
Refrigerant Selection* Built-in 87 common refrigerant PT comparison table for your convenience
Zero Function* Support for zero correction when deviation occurs at zero
Overload Alarm* If the pressure is over the range, the screen will display "ALARM". If the overload is too high, the ALARM & backlight will flash simultaneously.
Big LCD Screen* Big LCD screen (50x26mm) with backlight and visual display of various technical data in sections.
Auto OFF Time Adjustable* Auto-off time can be adjusted as per need.
Max/Min Value Memory* Max/Min value can be memorized after the gauge is on, and the value can be cleared manually.

Product Specifications

Pressure range Blue	0 - 500 psi
Resolution	0.001MPa, 0. 1psi
Accuracy	±0.5%FS
Sampling period	1s
Temperature unit	℃ / ℉
Backlight time	The backlight will be off after 3s, 4s, 5s, 10s or 15s as set in case of no operation.
LCD screen with blue backlight	50 x 26 mm
Measurement units	MPa, bar, psi, KPa, kg/cm 2, cmHg
Auto-off	If this function is enabled the gauge will be off automatically after 10 (or 20, 30, 40 )minutes per your settings. You may also disable this function by setting it as OFF, i. e the gauge will be on all the time.
Parameter settings	Auto-off, pressure/temperature unit, backlight time
Report	PT table lists the pressure and temperature of 87 types of common refrigerants
Battery	3 AAA batteries
Battery life	Approx. 1 year, Low battery indication at the low battery level
Operating environment	Temperature: -10℃~60℃; Humidity 35% - 85%RH
Overpressure alarm	ALARM shows on the top right of the screen if the blue gauge pressure goes above 500psi and the red gauge above 800psi; ALARM shows with backlight flashing if the blue gauge pressure goes above 625psi and the red gauge above 1000psi.
Package	Blister pack
Fitting	1/8 NPT
